الضغط:
7.5-13[ bar ]سعة التصريف:
1.99-56.15[ m3/min ]السلطة:
15-250[ kw ]
| Модель | Maxinmum working pressure | Capacity(FAD) | Installed motor power | driving mode&Cooling method | Dimensions(mm) | Weight(kg) | Noise level | Air outlet pipe diameter | EEI | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| bar(e) | psig | m3/min | cfm | kw | hp | L | W | H | kg | dB(A) | ||||
| DA-15+ | 7.5 | 109 | 2.38 | 84 | 15 | 20 | Direct Driven Air Cooling | 1350 | 800 | 1150 | 450 | 63±2 | G1 |
Enhanced EEI1 |
| 8.5 | 123 | 2.32 | 81.9 | 15 | 20 | |||||||||
| 10.5 | 152 | 2.02 | 71.3 | 15 | 20 | |||||||||
| 13 | 189 | 1.99 | 70.3 | 15 | 20 | |||||||||
| DA-18+ | 7.5 | 109 | 3.05 | 107.7 | 18.5 | 25 | 1350 | 800 | 1150 | 500 | 65±2 | G1 | ||
| 8.5 | 123 | 3.03 | 107 | 18.5 | 25 | |||||||||
| 10.5 | 152 | 3.02 | 106.6 | 18.5 | 25 | |||||||||
| 13 | 189 | 2.18 | 77 | 18.5 | 25 | |||||||||
| DA-22+ | 7.5 | 109 | 3.73 | 131.7 | 22 | 30 | 1350 | 800 | 1150 | 550 | 65±2 | G1-1/4 | ||
| 8.5 | 123 | 3.69 | 130.3 | 22 | 30 | |||||||||
| 10.5 | 152 | 3.09 | 109.1 | 22 | 30 | |||||||||
| 13 | 189 | 3.05 | 107.7 | 22 | 30 | |||||||||
| DA-30+ | 7.5 | 109 | 5.72 | 202 | 30 | 40 | 1450 | 900 | 1200 | 600 | 65±2 | G1-1/4 | ||
| 8.5 | 123 | 5.71 | 201.6 | 30 | 40 | |||||||||
| 10.5 | 152 | 4.32 | 152.5 | 30 | 40 | |||||||||
| 13 | 189 | 3.57 | 126.1 | 30 | 40 | |||||||||
| DA-37+ | 7.5 | 109 | 7.11 | 251.1 | 37 | 50 | 1600 | 1000 | 1400 | 650 | 65±2 | G1-1/4 | ||
| 8.5 | 123 | 6.7 | 236.6 | 37 | 50 | |||||||||
| 10.5 | 152 | 5.68 | 200.6 | 37 | 50 | |||||||||
| 13 | 189 | 4.56 | 161 | 37 | 50 | |||||||||
| DA-45+ | 7.5 | 109 | 7.99 | 282.1 | 45 | 60 | 1600 | 1000 | 1400 | 800 | 68±2 | G1-1/2 | ||
| 8.5 | 123 | 7.97 | 281.4 | 45 | 60 | |||||||||
| 10.5 | 152 | 7.93 | 280 | 45 | 60 | |||||||||
| 13 | 189 | 5.51 | 194.6 | 45 | 60 | |||||||||
| DA-55+ | 7.5 | 109 | 10.26 | 362.3 | 55 | 75 | 1800 | 1200 | 1400 | 850 | 68±2 | G1-1/2 | ||
| 8.5 | 123 | 10.15 | 358.4 | 55 | 75 | |||||||||
| 10.5 | 152 | 9.07 | 320.3 | 55 | 75 | |||||||||
| 13 | 189 | 7.56 | 266.9 | 55 | 75 | |||||||||
| DA-75+ | 7.5 | 109 | 15.36 | 542.4 | 75 | 100 | 1800 | 1200 | 1400 | 1450 | 72±2 |
G2 G2 G3 G4 |
||
| 8.5 | 123 | 15.29 | 539.9 | 75 | 100 | |||||||||
| 10.5 | 152 | 11.99 | 423.4 | 75 | 100 | |||||||||
| 13 | 189 | 11.62 | 410.3 | 75 | 100 | |||||||||
| DA-90+ | 7.5 | 109 | 21.38 | 754.9 | 90 | 120 | Direct Driven Air Cooling or Water Cooling | 2545 | 1300 | 1550 | 2000 | 72±2 | DN50 | |
| 8.5 | 123 | 20.74 | 732.3 | 90 | 120 | |||||||||
| 10.5 | 152 | 17.93 | 633.1 | 90 | 120 | |||||||||
| 13 | 189 | 15.12 | 533.9 | 90 | 120 | |||||||||
| DA-110+ | 7.5 | 109 | 23.11 | 816 | 110 | 150 | 2795 | 1600 | 1795 | 2600 | 75±2 | DN80 | ||
| 8.5 | 123 | 21.82 | 770.5 | 110 | 150 | |||||||||
| 10.5 | 152 | 19.33 | 682.5 | 110 | 150 | |||||||||
| 13 | 189 | 16.96 | 598.9 | 110 | 150 | |||||||||
| DA-132+ | 7.5 | 109 | 27.76 | 980.2 | 132 | 175 | 2800 | 1600 | 1800 | 2800 | 75±2 | DN80 | ||
| 8.5 | 123 | 26.24 | 926.5 | 132 | 175 | |||||||||
| 10.5 | 152 | 23.38 | 825.5 | 132 | 175 | |||||||||
| 13 | 189 | 20.52 | 724.6 | 132 | 175 | |||||||||
| DA-160+ | 7.5 | 109 | 34.33 | 1212.2 | 160 | 215 | 3000 | 1850 | 2000 | 3800 | 75±2 | DN80 | ||
| 8.5 | 123 | 33.25 | 1174.1 | 160 | 215 | |||||||||
| 10.5 | 152 | 27.86 | 983.7 | 160 | 215 | |||||||||
| 13 | 189 | 22.57 | 983.7 | 160 | 215 | |||||||||
| DA-185+ | 7.5 | 109 | 41.48 | 1464.7 | 185 | 250 | 3300 | 1950 | 2000 | 4200 | 75±2 | DN100 | ||
| 8.5 | 123 | 40.82 | 1441.4 | 185 | 250 | |||||||||
| 10.5 | 152 | 36.94 | 1304.4 | 185 | 250 | |||||||||
| 13 | 189 | 33.16 | 1170.9 | 185 | 250 | |||||||||
|
DA-200+ DA-200W+ |
7.5 | 109 | 43.64 | 1540.9 | 200 | 270 | 3300 | 1950 | 2000 | 4200 | 75±2 | DN100 | ||
| 8.5 | 123 | 42.98 | 1517.6 | 200 | 270 | |||||||||
| 10.5 | 152 | 39.1 | 1380.6 | 200 | 270 | |||||||||
| 13 | 189 | 35.32 | 1247.1 | 200 | 270 | |||||||||
|
DA-220+ DA-220W+ |
7.5 | 109 | 48.82 | 1743.8 | 220 | 300 | 3300 | 1950 | 2000 | 4200 | 78±2 | DN100 | ||
| 8.5 | 123 | 46.21 | 1631.7 | 220 | 300 | |||||||||
| 10.5 | 152 | 41.26 | 1456.9 | 220 | 300 | |||||||||
| 13 | 189 | 36.35 | 1283.5 | 220 | 300 | |||||||||
|
DA-250+ DA-250+ |
7.5 | 109 | 56.15 | 1982.7 | 250 | 350 | 3300 | 1950 | 2000 | 5400 | 82±2 | DN100 | ||
| 8.5 | 123 | 52.38 | 1849.5 | 250 | 350 | |||||||||
| 10.5 | 152 | 46.39 | 1638 | 250 | 350 | |||||||||
| 13 | 189 | 40.39 | 1426.2 | 250 | 350 | |||||||||
