الضغط:
7-10[ bar ]سعة التصريف:
6.38-46.99[ m3/min ]السلطة:
45-250[ kw ]
| Model | Maximum working pressure | Capacity(FAD) | installed motor power | Noise dB(A) | Dimensions(mm) | Weight | Air Outlet pipe Diameter | |||
|---|---|---|---|---|---|---|---|---|---|---|
| bar(e) | psig | m3/min | cfm | kw | hp | L*W*H | kg | |||
| DWW-45A/W | 7 | 102 | 8.11 | 286.4 | 45 | 60 | 67 |
A:2000×1200×1650
W:2300×1500×1720 |
2600 | 1-1/2" |
| 8 | 116 | 7.12 | 251.4 | 45 | 60 | 69 | 2600 | 1-1/2" | ||
| 10 | 145 | 6.38 | 225.3 | 45 | 60 | 71 | 2600 | 1-1/2" | ||
| DWW-55A/W | 7 | 102 | 10.21 | 360.5 | 55 | 75 | 68 | A:2000×1200×1650 | 2800 | 1-1/2" |
| 8 | 116 | 8.84 | 312.1 | 55 | 75 | 69 | 2800 | 1-1/2" | ||
| 10 | 145 | 8.12 | 286.7 | 55 | 75 | 71 | 2800 | 1-1/2" | ||
| DWW-65A/W | 7 | 102 | 11.58 | 408.9 | 65 | 90 | 68 |
A:2000×1200×1650
W:2300×1500×1720 |
2800 | 1-1/2" |
| 8 | 116 | 10.42 | 367.7 | 65 | 90 | 69 | 2800 | 1-1/2" | ||
| 10 | 145 | 12.1 | 45.9 | 65 | 90 | 71 | 2800 | 1-1/2" | ||
| DWW-75A/W | 7 | 102 | 12.91 | 455.9 | 75 | 100 | 69 |
A:2200×1400×2000
W:2300×1500×1720 |
2800 | DN50 |
| 8 | 116 | 12.83 | 435 | 75 | 100 | 71 | 2800 | DN50 | ||
| 10 | 145 | 11.57 | 408.5 | 75 | 100 | 72 | 2800 | DN50 | ||
| DWW-90W | 7 | 102 | 13.5 | 482 | 90 | 120 | 66 | W:2300×1500×1720 | 3400 | DN65 |
| 8 | 116 | 13.63 | 481.3 | 90 | 120 | 67 | 3400 | DN65 | ||
| 10 | 145 | 13.58 | 479.5 | 90 | 120 | 69 | 3400 | DN65 | ||
| DWW-110W | 7 | 102 | 20.44 | 721.7 | 110 | 150 | 67 | W:2700×1800×1800 | 3400 | DN65 |
| 8 | 116 | 19.95 | 704.4 | 110 | 150 | 68 | 3400 | DN65 | ||
| 10 | 145 | 19 | 670.9 | 110 | 150 | 70 | 3400 | DN65 | ||
| DWW-132W | 7 | 102 | 24.55 | 866.9 | 132 | 175 | 69 | W:2700×1800×1800 | 3450 | DN65 |
| 8 | 116 | 23.13 | 816.7 | 132 | 175 | 70 | 3450 | DN65 | ||
| 10 | 145 | 20.44 | 712.7 | 132 | 175 | 69 | 3450 | DN65 | ||
| DWW-160W | 7 | 102 | 28.79 | 1016.6 | 160 | 215 | 69 | W:2700×1800×1800 | 3550 | DN65 |
| 8 | 116 | 27.11 | 957.3 | 160 | 215 | 71 | 3550 | DN65 | ||
| 10 | 145 | 24.49 | 864.7 | 160 | 215 | 71 | 3550 | DN65 | ||
| DWW-180W | 7 | 102 | 31.5 | 1096.4 | 185 | 250 | 69 | W:2700×1800×1800 | 3950 | DN65 |
| 8 | 116 | 31.01 | 1095 | 185 | 250 | 71 | 3950 | DN65 | ||
| 10 | 145 | 28.72 | 1014.1 | 185 | 250 | 71 | 3950 | DN65 | ||
| DWW-200W | 7 | 102 | 37.14 | 1311.4 | 200 | 270 | 69 | W:3100×2100×2060 | 4500 | DN100 |
| 8 | 116 | 36.95 | 1305 | 200 | 270 | 70 | 4500 | DN100 | ||
| 10 | 145 | 31.13 | 1099.2 | 200 | 270 | 72 | 4500 | DN100 | ||
| DWW-220W | 7 | 102 | 41.13 | 1452.3 | 220 | 300 | 70 | W:2700×1800×1800 | 5000 | DN100 |
| 8 | 116 | 41.09 | 1450.9 | 220 | 300 | 71 | 5000 | DN100 | ||
| 10 | 145 | 34.47 | 1217.1 | 220 | 300 | 72 | 5000 | DN100 | ||
| DWW-250W | 7 | 102 | 46.99 | 1659.2 | 250 | 350 | 70 | W:3100×2100×2060 | 5200 | DN100 |
| 8 | 116 | 44 | 1553.6 | 250 | 350 | 72 | 5200 | DN100 | ||
| 10 | 145 | 41 | 1447.7 | 250 | 350 | 72 | 5200 | DN100 | ||
